Muni Tube Dewatering Tube Laydown Industrial Sludge Dewatering Municipal Sludge Dewatering Dredging Into Dewatering Tube Refinery Sludge Dewatering Industrial Sludge Dewatering Dredging Refinery Pond Contaminated Sediment Dewatering Refinery Sludge Dewatering Geotextile-tubes Hazardous Waste Dewatering Drilling Mud Dewatering Contaminated Sediment Dewatering Contaminated Waste Dewatering Mine Sediment Dewatering Drilling Mud Dewatering Contaminated Waste Dewatering Municipal Sludge Dewatering Mine Sediment Dewatering

Dewatering Tubes are also referred to as GeoTubes,  Geotextile dewatering bags, sludge bags, etc..   This process is widely used in most dredging and dewatering applications.  The dewatering containers are especially beneficial where the sludge is removed hydraulically like dredging or high-volume pumping.

The technology is based on filtration starting with the apparent opening size of the geotextile material.  As the sludge accumulates inside the dewatering tubes, the accumulated sludge becomes a filter as well resulting in cleaner effluent.  When dewatering organics or fine sediments a floculent or coagulant or combination can be added to the sludge to enhance both drying and purifying the effluent.

Our geotextile materials are manufactured with higher elasticity allowing higher flow rates and higher compaction rates.  Pumping rates into the dewatering tubes can be in excess of 8 times the rate of any other single dewatering device. This cost effective solution, when used correctly and optimized, will surpass the performance of other dewatering methods like centrifuges and belt presses.

Geotextile Dewatering Tubes are used for both raw water and wastewater and primary and secondary wastewater ponds.  The geotextile tube or Geotube technology is used in most industries including municipal, pulp and paper, mining, oilfield, marinas, construction water, etc.

High water reduction combined with a BOD reduction of up to 90% are also possible.  Agriculture operations with livestock, dairies and piggeries have also embraced the technology, which is simple, efficient and economical.

Our geotextile fabric contains UV protection keeping it from deteriorating for several years.  As the tube is a container the dewatered product can remain in the dewatering tube for several years to further dry the material.  Another benefit of leaving the sludge in the tube is to defer disposal costs so the costs may be spread over several years.

Advantages:

High flow rates along with the potential for leaving the dewatered sludge in the dewatering bag (container) make this technology unequaled.  The dewatering tubes can sit for years before removing sludge allowing for an extended disposal budget.

We have developed specialty polymers that enhance the throughput, water clarity (TSS) and sludge compaction.  Our polymers are fast activating and formulated for the sludge  and not “off the shelf” products.

Spinpro Dewatering Tubes:

Spinpro is a factory direct source for geotextile dewatering tubes.  Our high capacity  tubes are available in both polypropylene and polyester.  We stock standard and custom sizes up to 120′ circumference X 300′ long.  We supply our products and services world wide.

Spinpro is a full service company providing a complete package for your dewatering needs.  Our expertise is not just in the bags, but the entire project.  We have our own brand of proprietary polymers and coagulants ans well as hydration, pumping and dredging equipment. By choosing Spinpro you have a unified solution as opposed to purchasing the items and services separately.

We also produce hanging bags for testing, cubic yard bags and roll off dewatering bags for smaller projects.  Our support products also include liners, geo-grid, geo-membranes, silt fence, erosion control, turbidity curtains and silt screens.

Spinpro geotextile dewatering tubes save time, money and the environment.

Dewatering Tube Process

Dewatering Tubes:

Dewatering Tubes are filled with sediments containing sand, silt, clay or organics and or a combination all these sediments.  These type of container tubes are also used extensively in Industrial and Municipal applications.  In these applications the sludge is the product or waste from various processes.

Some sediments like sands, silts with low organic content can be dewatered without flocculent.  This type of filling is typical of dewatering tubes used for dykes or protecting shorelines.  The solid particles are trapped inside the geotextile material and the water is forced through the fabric.

Treatment:

Sludges with a high organic composition or manufactured sludge’s must be pre-treated.  The treatment consists of using conditioners such as polymers or coagulants.  This conditioning coagulates the particles together, so they are too large to pass through the woven material.

How Dewatering Tubes Work

Dewatering Tubes:

The dewatering tube material is designed as a filter but most the finer filtration is done by the material (dewatered sludge) in the tube.  As the water is squeezed from the sludge it passes through the accumulated sludge to exit the tube thereby scrubbing the water before release.

The result is optimum clarification, serving the purpose of both a dewatering device and a fine filter.  The dewatering tube is filled several times to maximize the compression on the dewatered sludge thereby drying the material.  Once the sludge has dried to the desired consistency the solid materials can be easily removed.

The amount of water removed depends on how long the material is left in the container and the conditioning of the sludge prior to entering the dewatering tube.  Areas with hotter weather will dry faster than cooler climates.  Areas with winter freezing also have an advantage as freezing sometimes helps sludges with high organic content release more of the water or liquids.

Disposal:

The residual sludge is excavated, transported and disposed of in an environmentally friendly way saving time and expense. The tube material has a degradation time of 7 -15 years depending on the application and u.v. protection in the material.  In beach erosion applications for lakes, marinas and waterways the tubes are left in place to stop shoreline erosion, build berms and dykes etc

Why SPINPRO Tubes

Spinpro Dewatering Tubes:

Spinpro dewatering tubes are designed for higher capacity and efficiency.  This allows for higher pumping rates, faster dewatering, and enhanced filtration with fewer bags.  Increased elasticity in the material combined with the strongest seams available help to manipulate the filling process.

Process:

We design our products and process to enhance and optimize your sludge dewatering project.  Production of the tubes can be ramped up to supply tubes for emergency spills and large orders.  We carry a large stock in both US and Canada as well.  With our guidance you will be able to meet or exceed water discharge specifications and dewatered sludge moisture content.

This results of optimization are lower transportation and disposal costs of the dewatered sludge as well as reduced water purification costs. When used properly our dewatering tubes are designed to save time, money and our environment.
